The histogram of an image shows the frequency of pixels’ intensity values. In an image histogram, the X-axis shows the gray level intensities and the Y-axis shows the frequency of these intensities.
Histogram equalization improves the contrast of an image, in order to stretch out the intensty range. You can equalize the histogram of a given image using the method equalizeHist() of the Imgproc class. Following is the syntax of this method.
equalizeHist(src, dst)
This method accepts the following parameters −
src − An object of the class Mat representing the source (input) image.
dst − An object of the class Mat representing the output. (Image obtained after equalizing the histogram)
The following program demonstrates how to equalize the histogram of a given image.
import java.util.ArrayList; import java.util.List; import org.opencv.core.Core; import org.opencv.core.Mat; import org.opencv.core.Size; import org.opencv.imgcodecs.Imgcodecs; import org.opencv.imgproc.Imgproc; public class HistoTest { public static void main (String[] args) { // Loading the OpenCV core library System.loadLibrary( Core.NATIVE_LIBRARY_NAME ); // Reading the Image from the file and storing it in to a Matrix object String file ="E:/OpenCV/chap20/histo_input.jpg"; // Load the image Mat img = Imgcodecs.imread(file); // Creating an empty matrix Mat equ = new Mat(); img.copyTo(equ); // Applying blur Imgproc.blur(equ, equ, new Size(3, 3)); // Applying color Imgproc.cvtColor(equ, equ, Imgproc.COLOR_BGR2YCrCb); List<Mat> channels = new ArrayList<Mat>(); // Splitting the channels Core.split(equ, channels); // Equalizing the histogram of the image Imgproc.equalizeHist(channels.get(0), channels.get(0)); Core.merge(channels, equ); Imgproc.cvtColor(equ, equ, Imgproc.COLOR_YCrCb2BGR); Mat gray = new Mat(); Imgproc.cvtColor(equ, gray, Imgproc.COLOR_BGR2GRAY); Mat grayOrig = new Mat(); Imgproc.cvtColor(img, grayOrig, Imgproc.COLOR_BGR2GRAY); Imgcodecs.imwrite("E:/OpenCV/chap20/histo_output.jpg", equ); System.out.println("Image Processed"); } }
Assume that following is the input image histo_input.jpg specified in the above program.
On executing the program, you will get the following output −
Image Processed
If you open the specified path, you can observe the output image as follows −
