Cordova - Camera

This plugin is used for taking photos or using files from the image gallery.

Step 1 - Install Camera Plugin

Run the following code in the command prompt window to install this plugin.

C:\Users\username\Desktop\CordovaProject>cordova plugin add cordova-plugincamera

Step 2 - Adding Button and Image

Now, we will create the button for calling the camera and img where the image will be displayed once taken. This will be added to index.html inside the div class = "app" element.

<button id = "cameraTakePicture">TAKE PICTURE</button>
<img id = "myImage"></img>

Step 3 - Adding Event Listener

The event listener is added inside the onDeviceReady function to ensure that Cordova is loaded before we start using it.

document.getElementById("cameraTakePicture").addEventListener
   ("click", cameraTakePicture);

Step 4 - Adding Functions (taking photo)

We will create the cameraTakePicture function that is passed as a callback to our event listener. It will be fired when the button is tapped. Inside this function, we will call the navigator.camera global object provided by the plugin API. If taking picture is successful, the data will be sent to the onSuccess callback function, if not, the alert with error message will be shown. We will place this code at the bottom of index.js.

function cameraTakePicture() {
   navigator.camera.getPicture(onSuccess, onFail, {
      quality: 50,
      destinationType: Camera.DestinationType.DATA_URL
   });

   function onSuccess(imageData) {
      var image = document.getElementById('myImage');
   }

   function onFail(message) {
      alert('Failed because: ' + message);
   }
}

When we run the app and press the button, native camera will be triggered.

When we take and save picture, it will be displayed on screen.

The same procedure can be used for getting image from the local file system. The only difference is the function created in the last step. You can see that the sourceType optional parameter has been added.

Step 1 B

C:\Users\username\Desktop\CordovaProject>cordova plugin add cordova-plugincamera

Step 2 B

<button id = "cameraGetPicture">GET PICTURE</button>

Step 3 B

document.getElementById("cameraGetPicture").addEventListener("click", cameraGetPicture);

Step 4 B

function cameraGetPicture() {
   navigator.camera.getPicture(onSuccess, onFail, { quality: 50,
      destinationType: Camera.DestinationType.DATA_URL,
      sourceType: Camera.PictureSourceType.PHOTOLIBRARY
   });

   function onSuccess(imageURL) {
      var image = document.getElementById('myImage');
      image.src = imageURL;
   }

   function onFail(message) {
      alert('Failed because: ' + message);
   }

}

When we press the second button, the file system will open instead of the camera so we can choose the image that is to be displayed.

This plugin offers lots of optional parameters for customization.
